CNC Precision Turned Components

CNC precision turned components are small rotational parts used as locating sleeves, optical spacers, instrument inserts and precision housings. They form part of optical assemblies, semiconductor-handling equipment and diagnostic instruments where several compact mechanical interfaces meet within one assembly.
Send Inquiry
Description
Technical Parameters

CNC Precision Turned Components



Core Advantages



Fine Control of Mating Dimensions

Machining tolerances reach ±0.004 mm on specified features. For a small locating insert seated inside an instrument body, this control narrows the variation in engagement between the insert and its mating bore and keeps the locating fit distinct from general body clearances.



Even Seating on Reference Faces

Flatness is controlled to ≤0.005 mm. When a spacer or mounting ring is clamped against a reference face, the controlled contact surface limits rocking caused by an uneven seat and provides a defined support plane for the next component in the stack.



Corrosion-Resistant Instrument Interfaces

316L stainless steel is available for wetted instrument components. Where aqueous cleaning solutions or process fluids contain chlorides, its molybdenum-bearing composition provides greater resistance to pitting than 304-series stainless steel at the exposed metal interface.

shopping001



Specifications and Parameters



Parameter Item

Technical Index

Processing Diameter Range

φ0.8mm - φ120mm

Processing Length Range

1mm - 350mm

Highest Dimensional Accuracy

±0.004mm

Optimal Surface Roughness

Ra 0.2μm

Geometric Tolerance

Coaxiality ≤0.008mm, Circular Runout ≤0.008mm, Flatness ≤0.005mm

Processable Materials

Aluminum alloy 6061-T6/7075-T6, stainless steel 304L/316L, titanium alloy TC4, superalloy Inconel 718, POM, PEEK, etc.

Surface Treatment

Hard anodizing, gold plating, silver plating, electroless nickel-phosphorus plating, passivation, ultra-precision polishing, laser marking, etc.

Processing Technology

Precision CNC turning, high-speed milling, deep hole drilling, precision tapping, honing, lapping, EDM, etc.



Customization



Custom CNC Precision Turned Components

Production follows the released drawing and its designated assembly references. The machining route combines precision turning with the required secondary operations, while the same revision is carried into the CNC programs and process documents used for manufacture.

Customizable Items

• Outside diameter: 0.8–120 mm

• Overall length: 1–350 mm

• Thin-wall and stepped-body geometry

• Internal recesses and bore profiles

• Thread size, pitch and engagement length

• Off-axis holes and milled flats

• Material grade and plated or anodized finish



Quality Control



  • First-piece inspection uses the drawing datum scheme rather than checking each dimension as an unrelated number. Coordinate and optical measurement cover feature location and small-edge geometry, including details that cannot be evaluated properly with a caliper alone.
  • Process sampling follows the machined features through successive operations. Surface texture is checked with a roughness instrument at the specified contact areas, while accessible dimensions are rechecked after finishing instead of accepting only the pre-finish measurements.
  • Every component receives a final check before packing. Inspection results are tied to the drawing revision and production lot; third-party inspection is accepted for orders that require an independent release check.



FAQ



Q: Are free samples available?

A: Free samples are available; freight is not included.

Q: What are the payment terms for custom components?

A: Custom orders use a 50% advance payment and a 50% balance payment.

Q: How is the orientation of a mounting face specified?

A: Specify perpendicularity or parallelism to the required datum.

Q: How should a flat-bottom blind bore be called out?

A: Specify the flat bottom explicitly on the drawing.
