Turned Components

Turned components are cylindrical and stepped machine parts, including bushings, spacers, threaded fittings and adjustment knobs. They are used in pump and valve assemblies, measuring instruments and textile machinery as connecting, spacing, guiding or manually adjusted elements.
Send Inquiry
Description
Technical Parameters

Turned Components



Core Advantages



Positive Axial Location
A stepped body with an integral shoulder provides a physical stop against the mating face. In a spacer or bushing assembly tightened from one end, that shoulder defines the seating position and reduces the number of loose locating elements in the assembly.


Grip for Manual Adjustment
Knurled outer surfaces give adjustment knobs and thumb-operated fittings a defined gripping texture. During repeated hand adjustment, the raised pattern provides purchase around the circumference and makes the grip surface distinct from the part's smooth locating sections.


Non-Metallic Sliding Contact
POM and nylon are available alongside metal grades. An unfilled POM bushing places a polymer contact surface between a moving shaft and its support, removing direct metal-to-metal rubbing at that interface while retaining a machined cylindrical form.

04-0693001



Specifications and Parameters



Parameter Item

Technical Index

Processing Diameter Range

φ3mm - φ150mm

Processing Length Range

3mm - 400mm

Dimensional Tolerance

±0.01mm - ±0.08mm

Surface Roughness

Ra 0.8μm - Ra 12.5μm (can be processed to Ra 0.4μm subsequently)

Geometric Tolerance

Coaxiality ≤0.02mm, Circular Runout ≤0.02mm

Processable Materials

Aluminum alloy 6061/7075, stainless steel 304/316, carbon steel 45#/Q235, brass H62, POM, nylon, etc.

Surface Treatment

Anodizing, electroplating zinc/nickel, blackening, plastic spraying, passivation, polishing, etc.

Processing Technology

CNC turning, drilling, tapping, milling, knurling, slotting, chamfering, etc.



Customization



Custom Turned Components

Components are produced to a technical drawing or to dimensions established from a reference part and released for manufacture. The production route follows the component's working interfaces, with the rotational shape established first and secondary features machined before the specified finishing operation.

Customizable Items

• Outside diameter: 3–150 mm

• Overall length: 3–400 mm

• Through-bores and blind bores

• Thread form, pitch and handedness

• Radial holes and end-face holes

• Slot position and end geometry

• Anodized, plated, black-oxide or polished finish



Quality Control



  • Stock checks distinguish the specified material grade and condition before machining starts. The first part establishes the approved setup, and process samples are checked as the run progresses to catch diameter changes or a shifted tool position.
  • Functional inspection includes thread condition, edge breaks and the transitions between machined features. A raised burr at a hole exit or an incomplete thread is treated as a separate defect even when the main outside dimensions are within the drawing limits.
  • Final inspection is completed on every component before packing. Remaining chips and machining residue are removed, and the part identity and quantity are matched to the order so visually similar variants are not mixed.



FAQ



Q: Are free samples available?

A: Free samples are available; freight is not included.

Q: What are the production lead times?

A: Standard products take 7–12 days; custom products take 10–15 days.

Q: What size information is needed for a shaft-and-bore fit?

A: Specify the upper and lower size limits for both mating parts.

Q: Will anodizing hide machining marks?

A: No. Specify the required surface preparation before anodizing.
